AGM Global Vision

AGM Rattler-C V2

Sensors up to 640 × 512 · NETD down to < 20 mK · up to 2,600 m detection · IP67

€785,95 EUR

RRP ~~€961,95 EUR~~ €785,95 EUR -18%

Sale Sold out

Taxes included.

Model AGM Rattler-C V2 19-256 AGM Rattler-C V2 35-384 AGM Rattler-C V2 50-640

Quantity

Authorised AGM Global Vision dealer

Ships from the Netherlands

3-year AGM limited warranty (Europe)

The AGM Rattler-C V2 is a thermal imaging clip-on that mounts in front of a day riflescope. It has 1× magnification, so you keep using your riflescope's own reticle and zoom. Choose a 256 × 192, 384 × 288 or 640 × 512 sensor. The 50-640 detects a 1.8 m target at up to 2,600 m.

Specifications

	19-256	35-384	50-640
Sensor	256 × 192	384 × 288	640 × 512
Detector	12 µm VOx	12 µm VOx	12 µm VOx
NETD	< 35 mK	< 20 mK	< 20 mK
Lens	19 mm F/1.0	35 mm F/1.0	50 mm F/1.0
Field of view	9.3° × 6.9°	7.5° × 5.6°	8.8° × 7.0°
Detection range (1.8 m target)	1,000 m	1,800 m	2,600 m
Battery life (Wi-Fi off)	11 h	11 h	9 h
Weight (no mount, no battery)	0.50 kg	0.54 kg	0.55 kg
Dimensions (no mount)	184 × 68 × 67 mm	184 × 68 × 67 mm	196 × 73 × 68 mm

Magnification	1×
Refresh rate	50 Hz
Display	0.39" OLED, 1024 × 768
Palettes	Black hot, White hot, Red hot, Fusion
Recording	Photo and video with audio, 16 GB built-in, shot-activated recording
Connectivity	Wi-Fi hotspot, AGM Connect app
Rangefinder	Stadiametric
Power	Replaceable rechargeable Li-ion (2 included), USB-C 5 V / 2 A
Protection	IP67
Max. recoil	1000 g / 0.4 ms
Operating temperature	-30 °C to +55 °C

Compatible with

Day riflescopes, with an AGM Front Q-R adapter that matches your scope's objective: 30 mm to 65 mm (sold separately)
AGM-2127 ADM QR mount (sold separately)
AGM eyepiece for handheld use as a thermal monocular (sold separately)
AGM Connect app for live view and file transfer

In the box

Rattler-C V2 clip-on
2 rechargeable batteries and charger
USB cable
Lens cloth and manual
Carrying case

FAQ

Which model should I choose?

The 19-256 is the entry model. The 35-384 has a more sensitive sensor (under 20 mK). The 50-640 has the highest resolution and the longest detection range.

Do I need an adapter?

Yes. Choose the Front Q-R adapter that matches the outside diameter of your riflescope's objective (30–65 mm). Contact us if you are not sure which size you need.

How long does the battery last?

Up to 11 hours (9 hours for the 50-640) with Wi-Fi off. Two replaceable batteries are included, and you can run it from USB-C power.

What recoil can it take?

AGM rates it for up to 1000 g / 0.4 ms.

What is the warranty?

3 years, under AGM's limited warranty in Europe.

Shipping, returns & warranty

Delivery: Usually dispatched within 1 week of order confirmation.
Ships from: Maasdijk, the Netherlands
Returns: 14 days to return the product (EU right of withdrawal). Return shipping is paid by the customer. Return policy
Warranty: 3-year AGM limited warranty (Europe)
Manufacturer: AGM Global Vision
Your country's laws: You are responsible for complying with the laws and regulations of your country when importing, owning or using this product.
Export control: This product may be subject to Regulation (EU) 2021/821 on the control of exports, brokering, technical assistance, transit and transfer of dual-use items.
