AGM Global Vision

AGM Rattler TC

Sensors up to 640 × 512 · 1× clip-on · up to 2,500 m range · IP67

€628,95 EUR

RRP ~~€701,80 EUR~~ €628,95 EUR -10%

Sale Sold out

Taxes included.

Model AGM Rattler TC19-256 AGM Rattler TC35-384 AGM Rattler TC35-640 AGM Rattler TC50-640

Quantity

Authorised AGM Global Vision dealer

Ships from the Netherlands

2-year AGM limited warranty (Europe); 3 years for the TC50-640

The AGM Rattler TC is a thermal clip-on that mounts in front of a day riflescope for hunting and observation at night. It has 1× magnification, so you keep using your riflescope's own reticle and zoom, and the eye relief does not change. Choose from four models, from the compact 19 mm unit with a 256 × 192 sensor to the 50 mm unit with a 640 × 512 sensor and an observation range of 2,500 m.

Specifications

	TC19-256	TC35-384	TC35-640	TC50-640
Sensor	256 × 192	384 × 288	640 × 512	640 × 512
Detector	12 µm VOx, uncooled	17 µm, uncooled	12 µm, uncooled	12 µm VOx, uncooled
Refresh rate	Sensor 25 Hz, display 50 Hz	50 Hz	50 Hz	Sensor 50 Hz, display 50 Hz
Lens	19 mm, F/1.0	35 mm, F/1.0	35 mm, F/1.0	50 mm, F/1.0
Field of view	9.2° × 6.9°	–	12.5° × 10.0°	8.8° × 7.0°
Range given by AGM	950 m (observation)	1,235 m (observation)	1,750 m (detection, 1.8 m target)	2,500 m (observation)
Display	0.39" OLED, 1024 × 768	0.39" OLED, 748 × 561	0.39" OLED, 1024 × 768	0.39" OLED, 1024 × 768
Day scope magnification	Up to 6×	Up to 8×	Up to 8×	Up to 8×
Weight	0.41 kg (no batteries)	0.42 kg	0.42 kg	0.49 kg (no batteries)
Dimensions	153 × 62 × 59 mm	153.2 × 62.5 × 59.2 mm	153.2 × 62 × 59 mm	153 × 78 × 66 mm

Magnification	1×
Diopter	-5 to +3 dpt
Distance measurement	Stadiametric (not a laser rangefinder)
Scene modes	Jungle, Recognition
Recording	Video and snapshots, 16 GB built-in
Connectivity	Wi-Fi, AGM Connect app
Power	2 × CR123A or RCR123A, external 5 V USB power
Battery life	Up to 4.5 hours
Mounting	Front quick-release adapter for the scope objective, or quick-release mount for Picatinny / Weaver rail (both sold separately)
Protection	IP67
Shock and vibration	750 g/ms
Operating temperature	-20 °C to +55 °C

Compatible with

Day riflescopes up to 6× (TC19-256) or up to 8× (TC35-384, TC35-640, TC50-640)
AGM ARM52 front Q-R adapters, 38 mm to 65 mm, to match the outside diameter of your scope's objective (sold separately)
AGM-2113 ADM single-lever QR mount, 1.03" height, and AGM-2114 ADM low-base QR mount, 0.78" height, for Picatinny / Weaver rails (sold separately)
AGM eyepiece for Rattler TC, part 6328ERC1, for handheld use as a thermal monocular (sold separately)
AGM passive thermal targets for zeroing, 25 or 50 pieces (sold separately)
AGM Connect app for live view and file transfer

In the box

Rattler TC clip-on
2 × CR123A lithium batteries
Universal front scope adapter mount
USB cable
Carrying case
Lens tissue and user manual
AGM cup (TC19-256, TC35-384 and TC50-640)
AGM backpack (TC50-640 only)

FAQ

Which model should I choose?

The TC19-256 is the compact entry model for short distances and scopes up to 6×. The TC35-384 and TC35-640 suit scopes up to 8×; the 640 model has the higher resolution. The TC50-640 has the longest range: 2,500 m.

Do I need an adapter?

To mount the clip-on in front of your scope, use an AGM ARM52 front Q-R adapter that matches the outside diameter of your scope's objective (38–65 mm). You can also mount it on a Picatinny / Weaver rail with an AGM ADM QR mount.

Which batteries does it use?

Two CR123A lithium or two RCR123A rechargeable batteries, for up to 4.5 hours. You can also power it from a 5 V USB source.

Can I use it handheld?

Yes, with the AGM eyepiece for Rattler TC (sold separately). It turns the clip-on into a handheld thermal monocular.

Shipping, returns & warranty

Delivery: Usually dispatched within 1 week of order confirmation.
Ships from: Maasdijk, the Netherlands
Returns: 14 days to return the product (EU right of withdrawal). Return shipping is paid by the customer. Return policy
Warranty: 2-year AGM limited warranty (Europe); 3 years for the TC50-640
Manufacturer: AGM Global Vision
Your country's laws: You are responsible for complying with the laws and regulations of your country when importing, owning or using this product.
Export control: This product may be subject to Regulation (EU) 2021/821 on the control of exports, brokering, technical assistance, transit and transfer of dual-use items.
