AGM Fuzion
AGM Fuzion
Thermal + visible fusion · 384 or 640 sensor · 16 GB recording · IP67
Couldn't load pickup availability
The AGM Fuzion is a handheld bi-spectrum monocular for hunting, wildlife observation and search in poor visibility. It combines a 12 µm thermal sensor with a low-light digital camera. You can view thermal, visible or a fused image, so heat sources appear on top of a normal picture of the terrain.
Specifications
Specifications
| TM25-384 | TM35-384 | TM35-640 | |
|---|---|---|---|
| Thermal sensor | 384 × 288 | 384 × 288 | 640 × 512 |
| Thermal lens | 25 mm F1.0 | 35 mm F1.0 | 35 mm F1.0 |
| Magnification | 2.5–20× | 3.5–28× | 2–16× |
| Field of view | 10.5° × 7.9° | 7.5° × 5.7° | 12.5° × 10.0° |
| Observation distance | 1,500 m | 1,653 m | 1,653 m |
| Dimensions | 161 × 87 × 51 mm | 168 × 87 × 51 mm | 168 × 87 × 51 mm |
| Weight (no battery) | 470 g | 480 g | 480 g |
| Thermal detector | 12 µm VOx, uncooled, 8–14 µm |
| Refresh rate | 50 Hz |
| Visible channel | 1/2" CMOS, 22 mm lens, 400–1000 nm |
| Digital zoom | 1×, 2×, 4×, 8× |
| Display | 0.39" OLED, 1024 × 768, 50 Hz |
| Palettes | Black hot, White hot, Red hot, Fusion, Visible, Image fusion |
| Hot spot tracking | Yes |
| Scene modes | Jungle, Recognition |
| Recording | Photo and video |
| Storage | 16 GB built-in |
| Video output | CVBS via USB |
| Connectivity | Wi-Fi hotspot, AGM Connect app |
| Battery | 1 × removable 18650, up to 5 h (Wi-Fi and CVBS off), up to 3 h (on) |
| Power | USB-C, 5 V / 2 A, external power supported |
| Protection | IP67 |
| Operating temperature | -20 °C to +55 °C |
| Diopter | -5 to +3 |
Compatible with
Compatible with
- AGM Connect app for live view and file transfer
- External USB-C power banks
In the box
In the box
- Fuzion monocular
- 2 × 18650 rechargeable batteries
- Battery charger
- USB cable and EU plug
- Rubber eyepiece
- Lens cloth
- User manual
FAQ
FAQ
What does image fusion do?
It lays the thermal image over the picture from the visible camera. You see heat sources and the terrain around them in one view.
Which model should I choose?
The TM25-384 is the most compact. The TM35-384 has more magnification. The TM35-640 has the highest thermal resolution and a wider field of view.
How long does the battery last?
Up to 5 hours with Wi-Fi and video output off, or up to 3 hours with them on. The 18650 battery is removable, and two are included with a charger.
Does it have a laser rangefinder?
No. For a built-in laser rangefinder, see the AGM Fuzion LRF.
