ARGUS BNVD-1431 MK2
ARGUS BNVD-1431 MK2
NNVT or Gen 3 tubes · FOM 1400+ to 2200+ · 500–580 g · IP68
Ships in 2–3 weeks
Couldn't load pickup availability
The Argus BNVD-1431 MK2 is a binocular night vision device for helmet or handheld use. It takes two 18 mm MX-10160 image intensifier tubes in a fibre-reinforced polymer housing. A built-in gravity sensor switches the device off when you flip it up and back on when you flip it down, so you do not need a separate switch.
Typical uses
- Night patrol and surveillance
- Search and rescue in low light
- Law enforcement and training at night
Specifications
Specifications
Configurations
| Tube | FOM | Phosphor | Features |
|---|---|---|---|
| NNVT NVT4 | 1400+ | Green | Non-autogated |
| NNVT NVT4 | 1400+ | White | Autogated |
| NNVT NVT5 | 1600+ | White | Autogated, MGC |
| NNVT NVT6 | 1800+ | White | Autogated, MGC |
| NNVT NVT7 | 2000+ | White | Autogated |
| NNVT NVT7 | 2200+ | White | Autogated, made to order |
| Gen 3 | 1600+ | Green or white | Complete kit: hard case, A4 mount, battery pack, cable |
| Gen 3 | 1800+ | Green or white | Complete kit: hard case, A4 mount, battery pack, cable |
| Image intensifier tubes | 2 × 18 mm, MX-10160 format |
| Magnification | 1× |
| Field of view | 40° ± 2° |
| Eyepiece diameter | 26 mm |
| Gain | Adjustable, depends on the tube |
| Pod flip angle | 140°, each pod flips on its own |
| Auto on/off | Gravity sensor; standby after 100 s without movement |
| IR illuminator | Built-in IR flood light |
| Mount interface | Standard Wilcox dovetail, quick release |
| Power | 1 × AA battery or external battery pack |
| Battery life | More than 15 h (1 × AA); more than 50 h (battery pack) |
| Housing | Fibre-reinforced polymer |
| Waterproof | IP68 |
| Operating temperature | -40 °C to +60 °C |
| Storage temperature | -55 °C to +70 °C |
| Dimensions (L × W × H) | 127 × 127 × 76 mm (5.0 × 5.0 × 3.0 in) |
| Weight | 500–580 g, depending on lenses |
Compatible with
Compatible with
- Helmet mounts with a standard Wilcox dovetail, such as the Argus A4 Lightweight NV Mount
- US military PVS-14 lenses (#A3256342), commercial 40° and 51° lenses, and ultra-light resin lenses
- External battery packs, such as the Argus Universal Strobe Battery Pack
- E-COTI and Jerry-C clip-on thermal imagers, for thermal fusion
In the box
In the box
- BNVD-1431 MK2 with the tubes you choose
- Gen 3 versions also include: hard case, A4 helmet mount, battery pack and cable
FAQ
FAQ
What does FOM mean?
Figure of merit is tube resolution multiplied by signal-to-noise ratio. A higher FOM gives a clearer image in low light.
How does the auto on/off work?
A gravity sensor turns the device off when you flip it up past a set angle and on again when you flip it down. After 100 seconds without movement it goes into standby. Press the power button 5 times to switch these functions off.
Can I use only one eye?
Yes. Each pod flips up and down on its own, so you can use one or both eyes.
How long does the battery last?
More than 15 hours on one AA battery, and more than 50 hours with an external battery pack at normal temperatures.
Shipping, returns & warranty
Shipping, returns & warranty
- Delivery
- Ships in 2–3 weeks
- Ships from
- Maasdijk, the Netherlands
- Returns
- 14 days to return the product (EU right of withdrawal). Return shipping is paid by the customer. Return policy
- Manufacturer
- Argus
- Your country's laws
- You are responsible for complying with the laws and regulations of your country when importing, owning or using this product.
- Export control
- This product may be subject to Regulation (EU) 2021/821 on the control of exports, brokering, technical assistance, transit and transfer of dual-use items.
